Yd-Et Specifications

•  Model: Yd-Et 450
•  Production Speed: 400 m/Min
•  Paper Width: 1800 Mm To 2800 Mm
•  Jumbo Roll Diameter: Up To 1500 Mm
•  Finished Roll Diameter: 100 Mm To 300 Mm
•  Unwind Stand: 1, 2, Or 3 Stands Available
•  Tail Sealing: Automatic
•  Embosser: Single Or Double Embossing
•  Driving System: Line Shaft And Belts
•  Optional Equipment: Edge Embossing And Lamination System
•  Jumbo Roll Core Inside Diameter: 76 Mm (Other Sizes Available Upon Request)
•  Finished Product Diameter: 180 Mm - 350 Mm
•  Jumbo Roll Diameter: 1500 Mm
•  Finished Product Core Inside Diameter: 40 Mm - 83 Mm
•  Sealing: Automatic Tail Sealing With Automatic Transfer To The Log Saw
•  Web Tension Control: Automatic Electronic Control
•  Driving System: Independent Drive System
•  Electrical Control System: Siemens Or Mitsubishi Controls
•  Optional Equipment: Thread-Up System, Deco Embosser And Lamination System, Point-To-Point Or Nested Embosser And Lamination Unit, Edge Embossing System
